Electric operating bed selection criteria and installation precautions
The electric integrated operating table is a reliable and efficient medical equipment in the ICU of the operating room. So, how to choose a comprehensive operating bed, and what are the installation points?
The selection criteria of comprehensive operating bed:
1. The specification of the purchased integrated operating bed should be 2200×900×500 mm. The bed surface is made of 1.2 mm thick cold-rolled steel plate, which is formed by one-time stamping and has no solder joints on the surface.
2. When purchasing a comprehensive operating bed, you should choose one equipped with a safe voltage linear motor, which has relatively stable performance and is equipped with a battery, which can work for four hours even if the power is cut off.
3. The head and tail of the comprehensive operating bed should be integrally blow-molded with high-quality materials, and the switches are set on the outside, which can be easily loaded and unloaded, and bedside cards can also be inserted.
Detailed analysis of the installation points of electric comprehensive operating table:
1. Installation of the headboard: According to the schematic diagram of the structure of the electric operating table, loosen the two plum blossom knobs under the neck of the backboard to a certain position, first insert the two fixing columns of the headboard into the holes of the backboard, and then tighten them The two plum blossom knobs under the neck position of the back plate, and then adjust the angle of the head plate according to the needs of the operation.
2. Installation of arm rests and leg rests: according to the structural diagram of the operating table, first loosen the plum blossom knobs on the corresponding locks at the parts of the arm rests and leg rests, and then insert the insertion rods of the arm rests and leg rests In the hole of the corresponding locker, adjust the height according to the needs of the operation, and then lock it securely.
3. Installation of shoulder card, waist card, anesthesia stand and other accessories: according to their positions, refer to the installation of arm rests and leg rests.
4. Debugging with the electric push rod as the power: according to the posture required for the operation, use the hand-held manipulator to control and adjust the electric lifting and the turning of each part. According to the instructions marked on the hand-held manipulator, click to achieve the best posture state. Release the handheld operator to lock itself.
5. Debugging with pneumatic spring as power: a pneumatic turning device is installed at the bottom of the corresponding pneumatic turning parts. To make the parts reach the required angle, there is a needle valve at the end of the piston rod of the self-locking gas spring. Use the specially installed handle (at the bottom) to open the needle valve, then the self-locking gas spring can freely adjust the position, so as to realize various actions on the operating table, release the needle valve, and the self-locking gas spring can lock itself in the current position , and the self-locking force is very large, which can realize the role of supporting the patient.
